• Backup battery option ensures guests can still use phone during power outages
• Mix and match up to 3 accessory Petites or handsets to optimize guest experience
• Antibacterial plastic tested to inhibit 99.9% of bacteria growth
• Backup battery matches handset battery, making it easy to inventory and swap in if the handset battery dies
• Backup battery option supports up to five hours in standby mode and two hours of talk time
• ENERGY STAR® qualified
• Adjustable RF transmission power prevents interference
• Handset Battery life: up to 7 hours of talk time with 7 days of standby time
• Expandable cordless system: up to a total of 4 cordless handsets
• Calls are digitized and encrypted, making eavesdropping nearly impossible
• Backlit handset dialpad
• Answer a call by simply picking up the handset from the charger
• Built-in speakerphone on both base and cordless handset
• Charging LED indicator feature ensures handset battery is charging
• DECT 6.0 technology eliminates interference from wireless networks and other wireless devices for superior sound quality
• Low battery indicator on cordless handset for easy maintenance
• Quickly locate all cordless handsets in the system using the Find Handset key
• Redial the last number called with the touch of a button; automatically expires in 15 minutes to protect guest privacy
• Register additional handsets quickly and easily
• Side handset volume control for easy access
• One non-removable, programmable message retrieval speed dial on handset
• One non-removable, programmable speed dial on base
• Two non-removable, programmable speed dials on handset
• Sturdy, solid construction ensures phone stays in place on the desk or nightstand
• Environmentally friendly ROHS program reduces the use of hazardous substances including lead, mercury and cadmium
• 0, 1, 3, 5 or 10 removable, programmable speed dials on base
• 5-year limited warranty
• Base dialpad
• Compatible with all major PBXs
• Desk or wall-mountable
• Flash, Hold, Mute, Redial and Conference
• Fully customizable faceplate for hotel brand and dialing instructions
• Hearing aid compatible
• Large, bright visual message waiting indicator alerts guests of new messages
• Multi-step volume control (ringer, handset and speakerphone)
• RJ11 port for fax or data
• Selectable ring tones

• Number of Lines: 2-Line
• SKU: 80-H0AZ-00-000
• Weight (in lbs): 2.6
• Temperature: 25o C ± 10o C
• Humidity: 65% ± 20%
• Radio Frequency: DECT 1.8GHz, DECT 1.9GHz
• Power Source: 6V DC External Power with Battery Backup
• Message Waiting Signal Type: FSK (Frequency-Shift Keying), High Voltage, Low Voltage, Panasonic, Reverse Polarity, Siemens
• Flash: Programmable timing (100/300/600ms)
• Cords: 12-foot standard coiled handset cord, 20-foot standard telephone line cord with RJ11 connectors
